Ethylene Propylene Diene Monomer (EPDM) gaskets are manufactured from a highly elastic synthetic rubber material and are a multi-purpose gasket suitable for a wide range of both indoor and outdoor applications.
With the ability to withstand both freezing and extremely high temperatures, these rubber gaskets are ideal for use in steam service duty, while their resistance to acids and alkaline makes them a good choice in a range of food processing plants. The synthetic material is also suitable for exterior applications including roofing, with its impermeable finish resistant to weather, ageing, abrasion, and water.
EPDM gaskets are categorised by grades including commercial-grade, WRAS approved, FDA approved, and flame and acid resistance. Our team have over 50 years of experience in gasket manufacture and are on hand to help you select the most effective materials for your application.
RELATED RUBBER PRODUCTS: Rubber Gaskets Overview | EPDM Rubber Gaskets | Neoprene Gaskets | Silicone Gaskets | Hypalon Gaskets | SBR Gaskets
A popular choice for utility companies, these gaskets are manufactured to BS 6920-1:2000 and BS 6920-1:2014 requirements, making them suitable for a range of applications involving water for human consumption.
Meeting EC 1935/2004 and FDA 21 CFR177.2600 regulations, these gaskets are often fabricated from non-toxic white materials for use in the manufacture of food and beverages, including alcohol, meat, and dairy.
A cost-effective alternative to other fire-resistant materials, our flame retardant EPDM gaskets have excellent tensile strength and are highly resistant to weathering, tearing, and exposure to the elements.
Conforming to ICI M228 specifications, these high-grade EPDM gaskets are resistant to highly abrasive processes, such as those using acids, alkalines and other chemicals.
Suitable for low pressure pipe seals, gaskets, weatherstrip, etc. Excellent water, ozone & UV resistant properties, vegetable oils, acids, aqueous chemicals, steam. It also has good mechanical properties and abrasion resistance.
Provides a cost-effective gasket solution, particularly well-suited for applications with low-pressure requirements where the material is not subjected to significant stress. Despite its economical nature, this grade maintains a level of weathering and ozone resistance, ensuring a balance between affordability and functional durability.
Blending commendable physical attributes with exceptional resistance to both weathering and ozone degradation, this material also exhibits effective resistance against certain mineral oils. These features culminate in a versatile material suitable for application across a broad spectrum of environments and use cases.
We are the only UK supplier of Boiler Seal, a high-quality EPDM polymer gasket, primarily used as a boiler door joint on both heritage and modern industrial boilers. The high-temperature capability combined with the sealing resilience expected from an elastomeric material makes it ideal for steam service duty
All of our EPDM gaskets are precision manufactured from a wide range of rubber sheet materials at our base in West Yorkshire. We have over 50 years’ experience in gasket manufacture, utilising our technical expertise and a range of CNC and punch-press machinery to ensure that gaskets are produced accurately and consistently for every client.
Many customers opt for our full turnkey manufacturing service, including CAD design, material specification, manufacture and global distribution. Alternatively, our experienced team use existing gaskets or clients’ designs and templates to produce single or multiple gaskets. All of our EPDM gaskets are supplied to recognised national and international standards, including WRAS, FDA, EC and ICI.
Rubber gaskets can be manufactured from an extensive range of graded sheet materials for both interior and exterior applications involving high temperatures and pressures, water, fuels and oils, among others.
With applications including food and water processing, it is paramount that the correct materials are selected to ensure compliance with strict national and international guidelines.
Please get in touch if you need help and advice about the correct sheet materials for your business. Our experienced team will be happy to help.
Our EPDM gaskets can be manufactured from a wide range of EPDM polymers in a range of shapes, sizes and thicknesses to suit client requirements. The table below outlines the optimum performance of a range of EPDM sheet materials as guidance to their typical operating characteristics. Please contact us for more information about the specific gasket materials for your application.
| Type | Temperature Range | Tensile Strength | Density |
| General Purpose EPDM | min -30 max 100 °C | 60 kg/cm2 | 1.38 g/cm2 |
| Flame Retardant EPDM | min - 30 max 100 °C | 70 kg/cm2 | 1.38 g/cm2 |
| Acid Resistant EPDM | min - 35 max 130 °C | 70 kg/cm2 | 1.38 g/cm2 |
| Soft Premium EPDM | min - 40 max 130 °C | 90 kg/cm2 | 1.25 g/cm3 |
| Commercial Grade EPDM | min - 30 max 110 °C | 50 kg/cm2 | 1.40 g/cm3 |
| Food Quality EPDM | min - 30 max 90 °C | 40 kg/cm2 | 1.35 g/cm2 |
| WRAS Approved EPDM | min - 15 max 90 °C | 110 kg/cm2 | 1.13 g/cm2 |
| Boiler Seal | min - 15 max 120 °C | - | - |
Our highly experienced technicians can advise you on the best sheet materials and manufacturing processes for a wide range of gasket applications.
EPDM gaskets are widely found in a multitude of everyday industrial and domestic applications. Due to their high resistance to environmental factors, temperatures and pressures, these versatile rubber gaskets can be used in both interior and exterior settings without losing their elasticity and sealing abilities. Our experienced team are on hand to advise you about the best material for your application.
We supply a vast range of gasket materials, available to buy directly or order from us. For more information visit the Gasket Sheet Materials page
